- CUSTOMISABLE BOSCH SMART SYSTEM WITH PERFORMANCE CX E-DRIVE, KIOX 300 DISPLAY AND 750 (SIZE XS AND S: 625) WH BATTERY
- OFFROAD-READY MOUNTAIN BIKE GEOMETRY WITH 29" WHEELS (SIZE XS: 27,5") AND SHIMANO DEORE 11-SPEED SHIFTING
- COMFORTABLE COCKPIT, C.I.S. STEM WITH INTEGRATED CABLE ROUTING AND ROCKSHOX RECON AIR SUSPENSION FORK
ESCAPE THE DAILY GRIND
SUPER POWERFUL AND DYNAMIC E-MOTOR
The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. A well-balanced geometry makes the JARIFA ride agile and dynamic. The strongest e-motor of Bosch is perfectly integrated into the bottom bracket area.
RECORD-BREAKING INTEGRATED RANGE AND A NEW DISPLAY
The new Bosch Powertube battery (smart system) with its record-breaking 750 Wh (size XS and S: 625 Wh) is perfectly integrated into the down tube, yet it can also be removed at any time for charging. Furthermore, the latest Kiox 300 offers a bigger, easier-to-read display with a new remote and better ergonomics. Additionally, a USB-C port on the top tube gives you the opportunity to charge your devices.
EXTRA-COMFORTABLE, INTEGRATED AND EASY TO RETROFIT
The JARIFA combines MTB and trekking DNA. The cockpit with a 30-degree stem and ergonomic parts make your ride comfortable even on rides off the beaten track. The C.I.S. (Cockpit Integration Solution) technology offers a clean cockpit with cable routing through stem and headset into the frame. Additionally, the JARIFA can be retrofitted easily thanks to respective mounting points. On top, the JARIFA 6.8 is approved for most trailers and for a system weight (rider plus gear and bike) of 150 kg. Considering the needs of smaller riders, the JARIFA models in size XS roll on 27,5" wheels.
| FRAME MATERIAL | Aluminium |
| FRAME | 7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, USB-C port, post mount 180 mm |
| FORK | SR Suntour XCR 34 LO Air, 15x110 mm |
| TRAVEL OF SUSPENSION FORK | 100 mm |
| MOTOR | Bosch Performance CX Smart, 85 Nm, 250 W |
| BATTERY WATT-HOURS | 625 Wh (XS, S), 750 Wh (M, L, XL) |
| BATTERY AMPERE HOURS | 17.4 Ah (XS, S), 20.8 Ah (M, L, XL) |
| DISPLAY | Bosch LED Remote Kiox 300 |
| SHIFTER | Shimano Deore M5100, 11-speed |
| REAR DERAILLEUR | Shimano Deore RD-M5100, 11-speed |
| SPROCKET | Shimano Deore CS-M5100, 11-speed |
| CHAIN | Shimano CN-HG601, 11-speed |
| CRANKSET | FSA CK-320, aluminium |
| TRANSMISSION OF DRIVE | Front: 36T, Rear: 11-51T |
| BOTTOM BRACKET | Integrated in Drive Unit |
| HANDLEBAR | Aluminium, 760 mm, flatbar, backsweep: 9, 35,0 mm |
| STEM | FOCUS C.I.S. integrated, 60 mm, 30, 35 mm, aluminium |
| HEADSET | ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated |
| SADDLE | Selle Royal Vivo |
| SEATPOST | Aluminium, 31.6 mm |
| BRAKE CALIPER | Shimano MT410, 2-piston, hydraulic disc brake |
| BRAKE LEVER | Shimano MT410 |
| BRAKE | Disc |
| RIMS | RODI TRYP25, 25-622 |
| REAR HUB | Shimano Alivio MT400, 12x148 mm |
| FRONT HUB | Shimano Alivio MT400, 15x110 mm |
| TIRES | Schwalbe Smart Sam 2.25, 57-622, Schwalbe Smart Sam, 57-584 (XS) |
| GEARS | 11 |
| BIKE WEIGHT INCL. BATTERY IN KG | *24.2 kg, 27.2 kg |
| SHIFTING TYPE | Mechanical shifting |
| SIZE | XS, S, M, L, XL |
Speed limit for e-support in New Zealand is 32 km/h. Our e-bikes are adjusted accordingly.
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
