Kona Process X DH - Purple

Playful riders rejoice introducing the aluminum Process X DH. For downhill enthusiasts who like to ride outside of the lines, no side hit is safe from tires attached to the Process X DH. Agile enough in the rear end to win Whip Offs, yet stable enough to absorb some of the biggest hits and inside lines. It offers you everything you need in a bike to become a park rat overnight.

Specification

Frame Material	Kona 6061 Aluminum Butted 162mm Travel
Sizes	S, M, L, XL
Rear Shock	RockShox Super Deluxe Coil Trunnion
Fork	RockShox Boxxer Select DebonAir 190mm
Crankarms	Race Face Aeffect R
Chainrings	34t
B/B	Race Face PF92
Pedals	n/a
Chain	KMC X9
Cassette	SRAM PG920 11-34t 9spd
Chainguide	MRP
F/D	n/a
R/D	SRAM X7
Shifters	SRAM X5
Brake Calipers	SRAM Guide T
Front Brake Rotor	SRAM Centerline 200mm
Rear Brake Rotor	SRAM Centerline 200mm
Brake Levers	SRAM Guide T
Headset	FSA Orbit 1.5 EP ZS
Handlebar	Kona XC/BC 35
Stem	Race Face Chester
Seatpost	Kona OB 31.6mm
Seat Clamp	Kona Clamp
Grips	Kona Key Grip
Saddle	WTB Volt
Front Hub	Formula 110x20mm
Rear Hub	Formula 148x12mm
Spokes	Stainless Black 14g
Rims	WTB ST i30 TCS 2.0
Front Tyre	Maxxis Assegai DH 29x2.5" WT
Rear Tyre	Maxxis Minion DHR II DH 27.5x2.4" WT
Paint Color	Gloss Metallic Grape w/ Furnace Fade & Purple Decals

Geometry

	Size	XS	S	M	L	XL
1	ST Length	360	385	410	450	485
2	TT Length	537	567	596	625	664
3	Reach	400	425	450	475	510
4	Stack	585	595	605	615	626
5	Standover	674	687	712	712	711
6	HT Angle	66	66	66	66	66
7	HT Length	116	127	138	149	160
8	ST Angle	76.8	76.6	76.5	76.3	76.2
9	CS Length	425	425	425	425	425
10	BB Drop	12	12	12	12	12
11	BB Height	343	343	343	343	343
12	Wheelbase	1131	1160	1190	1219	1259
13	Front Center	706	735	765	794	834
14	Fork Length	532	532	532	532	532
15	Fork Offset	46	46	46	46	46
